package hello;

import java.awt.Color;
import java.awt.image.BufferedImage;
import java.awt.image.Raster;
import java.awt.image.WritableRaster;
import java.io.File;
import java.io.IOException;
import java.io.StringWriter;
import java.util.HashMap;
import java.util.Map;

import javax.imageio.ImageIO;

import org.geotools.coverage.grid.GridCoverage2D;
import org.geotools.coverage.grid.io.AbstractGridFormat;
import org.geotools.coverage.grid.io.GridCoverage2DReader;
import org.geotools.coverage.grid.io.GridFormatFinder;
import org.geotools.data.DataStore;
import org.geotools.data.DataStoreFinder;
import org.geotools.data.FeatureSource;
import org.geotools.feature.FeatureCollection;
import org.geotools.filter.text.cql2.CQLException;
import org.geotools.filter.text.ecql.ECQL;
import org.geotools.geojson.feature.FeatureJSON;
import org.geotools.referencing.CRS;
import org.opengis.feature.simple.SimpleFeature;
import org.opengis.feature.simple.SimpleFeatureType;
import org.opengis.filter.Filter;
import org.opengis.geometry.Envelope;
import org.opengis.referencing.FactoryException;
import org.opengis.referencing.NoSuchAuthorityCodeException;
import org.opengis.referencing.crs.CRSAuthorityFactory;
import org.opengis.referencing.crs.CoordinateReferenceSystem;
import org.opengis.referencing.operation.MathTransform;
import org.opengis.referencing.operation.TransformException;

public class TestGeoTools {

  /**
     * GeoTIFF to PNG 변경
     *
     * @param sourceFilePath
     * @param targetFilePath
     * @return boolean
     * @throws IOException
     */
  public static boolean convertGeoTiffToPng(String sourceFilePath, String targetFilePath) throws IOException {

    File file = new File(sourceFilePath);

    if (!file.exists()) {
      System.out.println("file not found");
      return false;
    }

    // AbstractGridFormat format = GridFormatFinder.findFormat(file);
    // System.out.println(format.getName());
    BufferedImage img = ImageIO.read(file);

    int width = img.getWidth();
    int height = img.getHeight();

    Raster raster = img.getData();
    int bands = raster.getNumBands();

    System.out.println("raster bands: " + bands);

    BufferedImage saveimage = null;
    WritableRaster dest = null;

    switch (bands) {
    case 1:
      saveimage = new BufferedImage(img.getWidth(), img.getHeight(), BufferedImage.TYPE_INT_RGB);
      saveimage.createGraphics().drawImage(img, 0, 0, Color.white, null);
      break;
    case 3:
      // Create an identically-sized output raster
      dest = raster.createCompatibleWritableRaster();

      for (int x = 0; x < width; x++) {
        for (int y = 0; y < height; y++) {
          // Copy the pixel
          double[] pixel = new double[bands];
          pixel = raster.getPixel(x, y, pixel);
          if (pixel[0] > 255 && pixel[0] > 255 && pixel[0] > 255) {
            pixel[0] = 255;
            pixel[1] = 255;
            pixel[2] = 255;
          }
          dest.setPixel(x, y, pixel);
        }
      }

      // Save the raster back to the Image
      saveimage = new BufferedImage(width, height, BufferedImage.TYPE_INT_RGB);
      saveimage.setData(dest);

      break;
    case 4:
      // Create an identically-sized output raster
      dest = raster.createCompatibleWritableRaster();

      for (int x = 0; x < width; x++) {
        for (int y = 0; y < height; y++) {
          // Copy the pixel
          double[] pixel = new double[bands];
          pixel = raster.getPixel(x, y, pixel);
          dest.setPixel(x, y, pixel);
        }
      }

      // Save the raster back to the Image
      saveimage = new BufferedImage(width, height, BufferedImage.TYPE_INT_ARGB);
      saveimage.setData(dest);

      break;
    }
    // Write the new file
    ImageIO.write(saveimage, "png", new File(targetFilePath));
    return true;

  }

  /**
     * GeoTIFF 에서 Extent값 가져옴
     *
     * @param sourceFilePath
     * @return extent
     * @throws IOException
     */
  public static double[] getExtentFromGeoTiff(String sourceFilePath) throws IOException {

    File file = new File(sourceFilePath);
    AbstractGridFormat format = GridFormatFinder.findFormat(file);
    GridCoverage2DReader reader = format.getReader(file);
    GridCoverage2D coverage = (GridCoverage2D) reader.read(null);
    Envelope env = coverage.getEnvelope();

    double minX = env.getLowerCorner().getOrdinate(0);
    double minY = env.getLowerCorner().getOrdinate(1);
    double maxX = env.getUpperCorner().getOrdinate(0);
    double maxY = env.getUpperCorner().getOrdinate(1);

    System.out.println("getGeoTiffExtent=" + coverage.getCoordinateReferenceSystem2D().getName().toString() + " " + coverage.getName() + ": " + minX + "," + minY + "  " + maxX + "," + maxY);

    double[] extent = new double[4];
    extent[0] = minX;
    extent[1] = minY;
    extent[2] = maxX;
    extent[3] = maxY;

    return extent;
  }

  /**
     * SHP파일에서 GeoJson가져옴
     *
     * @param shpFilePath
     * @param charset
     * @param mapEPSG
     * @param bbox
     * @return geojson string
     * @throws IOException
     * @throws NoSuchAuthorityCodeException
     * @throws FactoryException
     * @throws TransformException
     * @throws CQLException
     */
  public static String getGeoJsonFromShp(String shpFilePath, String charset, String mapEPSG, String bbox)
  throws IOException,
  NoSuchAuthorityCodeException,
  FactoryException,
  TransformException,
  CQLException {

    // 파일 읽기
    File file = new File(shpFilePath);
    Map < String,
    Object > map = new HashMap < >();
    map.put("url", file.toURI().toURL());
    map.put("create spatial index", true);
    map.put("charset", charset); // encode

    System.out.println("charset::" + charset);

    DataStore dataStore = DataStoreFinder.getDataStore(map);
    String typeName = dataStore.getTypeNames()[0];
    FeatureSource < SimpleFeatureType,
    SimpleFeature > source = dataStore.getFeatureSource(typeName);

    CRSAuthorityFactory factory = CRS.getAuthorityFactory(true);

    CoordinateReferenceSystem mapCRS = factory.createCoordinateReferenceSystem(mapEPSG); // CRS.decode(srsName);
    CoordinateReferenceSystem srcCRS = dataStore.getSchema(typeName).getCoordinateReferenceSystem();
    System.out.println("dataCRS.toWKT() :: " + srcCRS.toWKT());
    System.out.println("mapCRS.toWKT() :: " + mapCRS.toWKT());

    boolean lenient = true; // allow for some error due to different datums
    MathTransform transform = CRS.findMathTransform(mapCRS, srcCRS, lenient);

    String[] bbox_str = bbox.split(",");

    double[] param_bbox = new double[4];
    param_bbox[0] = Double.parseDouble(bbox_str[0]);
    param_bbox[1] = Double.parseDouble(bbox_str[1]);
    param_bbox[2] = Double.parseDouble(bbox_str[2]);
    param_bbox[3] = Double.parseDouble(bbox_str[3]);

    double[] srcProjec1 = {
      param_bbox[0],
      param_bbox[1]
    }; // easting, northing,
    double[] srcProjec2 = {
      param_bbox[2],
      param_bbox[3]
    }; // easting, northing,

    double[] dstProjec1 = {
      0,
      0
    };
    double[] dstProjec2 = {
      0,
      0
    };

    transform.transform(srcProjec1, 0, dstProjec1, 0, 1);
    transform.transform(srcProjec2, 0, dstProjec2, 0, 1);

    String filter_bbox = dstProjec1[0] + "," + dstProjec1[1] + "," + dstProjec2[0] + "," + dstProjec2[1];
    System.out.println("filter_bbox: " + filter_bbox);

    Filter filter = Filter.INCLUDE; // ECQL.toFilter("BBOX(THE_GEOM, 10,20,30,40)")
    if (!filter_bbox.isEmpty()) {
      filter = ECQL.toFilter("BBOX(the_geom," + filter_bbox + ")"); // ECQL.toFilter("BBOX(THE_GEOM,
      // 10,20,30,40)")
    }

    FeatureCollection < SimpleFeatureType,
    SimpleFeature > collection = source.getFeatures(filter);

    FeatureJSON featureJson = new FeatureJSON();
    StringWriter writer = new StringWriter();
    featureJson.writeFeatureCollection(collection, writer);

    String geojson = writer.toString();

    return geojson;
  }

}

testfabricjs + openlayers test

<%@page language = "java" pageEncoding = "utf-8" import = "java.io.*,java.net.URL,java.net.URLConnection,org.apache.commons.io.IOUtils" %>
<%
String GET_URL = request.getParameter("url");

URL tempURL = new URL(GET_URL);
byte[] bytes = null;
URLConnection conn = tempURL.openConnection();
bytes = IOUtils.toByteArray(conn.getInputStream());

System.out.println("bytes Length: " + bytes.length);

String THIS_URL = request.getRequestURL().toString();
String PROXY_URL = THIS_URL + "?url=";

System.out.println("GET_URL : " + GET_URL);
System.out.println("THIS_URL : " + THIS_URL);
System.out.println("PROXY_URL : " + PROXY_URL);

String contentType = conn.getContentType();
response.setContentType(contentType);

System.out.println("contentType: " + contentType);

if (GET_URL.contains("cur") || contentType.contains("image")) {
  out.clear();
  out = pageContext.pushBody();

  byte[] data = bytes;
  response.setHeader("Content-length", Integer.toString(data.length));
  response.setHeader("Accept-Ranges", "bytes");
  response.setHeader("Access-Control-Allow-Origin", "*");
  response.setContentType("text/plain;charset=UTF-8");

  response.getOutputStream().write(data, 0, data.length);
  response.getOutputStream().flush();

}
else {

  String output = new String(bytes);
  System.out.println("contentLength: " + output.length());

  output = output.replace("http://static.naver.net", PROXY_URL + "http://static.naver.net");
  output = output.replace("https://ssl.pstatic.net/static", PROXY_URL + "https://ssl.pstatic.net/static");
  output = output.replace("return\"http://\"+this.prefix+\"onetile\"", "return\"" + PROXY_URL + "http://\"+this.prefix+\"onetile\"");

  output = output.replace("_parse:function(t){var e=t.split", "_parse:function(t){t='" + GET_URL + "';var e=t.split");

  String temp = THIS_URL.replace(request.getScheme() + "://", "") + "?url=" + request.getScheme() + "://openapi.map.naver.com";
  output = output.replace("_sync:function(t,e){i.forEach(t,function(t){", "_sync:function(t,e){i.forEach(t,function(t){t=t.replace(location.hostname,'" + temp + "');");

  output = output.replace("&uri", "%26uri");
  output = output.replace("&useStyleMap", "%26useStyleMap");
  output = output.replace("&time", "%26time");
  output = output.replace("(F?\"https\":\"http\")", "(F?\"" + PROXY_URL + "https\":\"" + PROXY_URL + "http\")");
  output = output.replace("&\")+s.callbackname", "%26\")+s.callbackname");

  output = output.replace("!u.test(e)", "u.test(e)");

  output = output.replace("e=\"\";", "e=\"\";e=decodeURIComponent(e);e=e.split('url')[1];");
  output = output.replace("http://rts1.map.naver.net", PROXY_URL + "http://rts1.map.naver.net");

  //output = output.replace("removeDOMListener:function(t,n,o){", "removeDOMListener:function(t,n,o){console.log(t);console.log(i);");

  out.print(output);
}

System.out.println("");
%>

var INCHES_PER_UNIT = { 'm': 39.37, 'dd': 4374754 };
var DOTS_PER_INCH = 72;

/** * @param {number} resolution Resolution.
* @param {string} units Units
* @param {boolean=} opt_round Whether to round the scale or not.
* @return {number} Scale */
var getScaleFromResolution = function(resolution, units, opt_round) {
var scale = INCHES_PER_UNIT[units] * DOTS_PER_INCH * resolution;
  if (opt_round) {
    scale = Math.round(scale);
  }
  return scale;
};

var units = map.getView().getProjection().getUnits();
var INCHES_PER_UNIT = {
  'm': 39.37,
  'dd': 4374754
};
var DOTS_PER_INCH = 72;

/**
 * @param {number} resolution Resolution.
 * @param {string} units Units
 * @param {boolean=} opt_round Whether to round the scale or not.
 * @return {number} Scale
 */
var getScaleFromResolution = function(resolution, units, opt_round) {
  var scale = INCHES_PER_UNIT[units] * DOTS_PER_INCH * resolution;
  if (opt_round) {
    scale = Math.round(scale);
  }
  return scale;
};


function mapScale (dpi) {
    var unit = map.getView().getProjection().getUnits();
    var resolution = map.getView().getResolution();
    var inchesPerMetre = 39.37;

    return resolution * ol.proj.METERS_PER_UNIT[unit] * inchesPerMetre * dpi;
}



https://gis.stackexchange.com/questions/242424/how-to-get-map-units-to-find-current-scale-in-openlayers

SELECT CASE
    WHEN X.GTYPE = 1 THEN 'POINT'
    WHEN X.GTYPE  = 2 THEN 'LINE'
    WHEN X.GTYPE  = 3 THEN 'POLYGON'
    WHEN X.GTYPE  = 4 THEN 'COLLECTION'
    WHEN X.GTYPE  = 5 THEN 'MULTIPOINT'
    WHEN X.GTYPE  = 6 THEN 'MULTILINE'
    WHEN X.GTYPE  = 7 THEN 'MULTIPOLYGON'
        ELSE 'GEOMETRY' END GTYPE
    FROM
        (SELECT MAX(A.GEOMETRY.GET_GTYPE()) GTYPE FROM TGE_B_ADM_EMD_A A WHERE ROWNUM<1000) X
;

// shp to oracle
java -classpath .\ojdbc6.jar;.\sdoutl.jar;.\sdoapi.jar oracle.spatial.util.SampleShapefileToJGeomFeature
-h 192.168.252.130 -p 1521 -s orcl -u test -d 1111 -f D:\temp2\test\TGE_T_GGS_P -r 3857 -g geometry -i fid -t TGE_T_GGS_P


// geometry 인덱스 생성
CREATE INDEX TGE_T_GGS_P_GEOM_IDX ON TGE_T_GGS_P (GEOMETRY) INDEXTYPE IS MDSYS.SPATIAL_INDEX;

// fid 유니크 인덱스 생성
CREATE UNIQUE INDEX TGE_T_GGS_P_UIDX ON TGE_T_GGS_P( FID );


SELECT * FROM MDSYS.USER_SDO_GEOM_METADATA;

package test;

import org.osgeo.proj4j.CRSFactory;
import org.osgeo.proj4j.CoordinateReferenceSystem;
import org.osgeo.proj4j.CoordinateTransform;
import org.osgeo.proj4j.CoordinateTransformFactory;
import org.osgeo.proj4j.ProjCoordinate;

/*
 * maven import
 *
  <dependency>
  <groupId>org.osgeo</groupId>
  <artifactId>proj4j</artifactId>
  <version>0.1.0</version>
</dependency>

 */

public class Main {

  public static void main(String[] args) {
    ProjCoordinate trans = transform(14203089.275873486, 4414526.262702693);
    System.out.format("%s, %s", trans.x, trans.y);
  }

  public static ProjCoordinate transform(Double x, Double y) {

    CoordinateTransformFactory ctFactory = new CoordinateTransformFactory();
    CRSFactory csFactory = new CRSFactory();
    CoordinateReferenceSystem GOOGLE = csFactory.createFromParameters("EPSG:3857", "+proj=merc +a=6378137 +b=6378137 +lat_ts=0.0 +lon_0=0.0 +x_0=0.0 +y_0=0 +k=1.0 +units=m +nadgrids=@null +wktext +no_defs");
    CoordinateReferenceSystem WGS84 = csFactory.createFromParameters("WGS84", "+proj=longlat +datum=WGS84 +no_defs");
    CoordinateTransform trans = ctFactory.createTransform(GOOGLE, WGS84);
    ProjCoordinate p = new ProjCoordinate();
    ProjCoordinate p2 = new ProjCoordinate();
    p.x = x;
    p.y = y;
    return trans.transform(p, p2);

  }

}

출처 https://www.osgeo.kr/205

function drawbbox() {
    var bbox = map.getView().calculateExtent();
    var coord = [[
        [bbox[0], bbox[1]],
        [bbox[0], bbox[3]],
        [bbox[2], bbox[3]],
        [bbox[2], bbox[1]],
        [bbox[0], bbox[1]]
    ]];

    var geojsonObject = {
        'type': 'FeatureCollection',
        'crs': {
            'type': 'name',
            'properties': {
                'name': 'EPSG:3857'
            }
        },
        'features': [{
            'type': 'Feature',
            'geometry': {
                'type': 'Polygon',
                'coordinates': coord
            }
        }]
    };

    var bboxSource = new ol.source.Vector({
        features: new ol.format.GeoJSON().readFeatures(geojsonObject)
    });

    var bbox = new ol.layer.Vector({
        name: 'Select',
        source: bboxSource,
        style: new ol.style.Style({
            stroke: new ol.style.Stroke({
                color: 'blue'
            }),
            fill: new ol.style.Fill({
                color: [0, 0, 255, 0.05]
            })
        })
    });
    map.addLayer(bbox);
}

참고,

https://docs.geoserver.org/stable/en/user/data/database/primarykey.html#metadata-table-description

https://docs.geoserver.org/latest/en/user/data/database/oracle.html#using-the-geometry-metadata-table

c# project

release

첨부파일 확인

--구글 좌표계 900913, 3857
--서부원점(bassel)- EPSG:5173
--중부원점(bassel)- EPSG:5174
--제주원점(bassel)- EPSG:5175
--동부원점(bassel)- EPSG:5176
--동해울릉원점(bassel)- EPSG:5177
--UTM-K(Bessel 1841) EPSG:5178
--UTM-K(GRS80) EPSG: 5179
--서부원점(GRS80) EPSG: 5180 (False_Easting: 200000.0 , False_Northing: 500000.0)
--중부원점(GRS80) EPSG: 5181 (False_Easting: 200000.0 , False_Northing: 500000.0)
--제주원점(GRS80) EPSG: 5182 (False_Easting: 200000.0 , False_Northing: 550000.0)
--동부원점(GRS80) EPSG: 5183 (False_Easting: 200000.0 , False_Northing: 500000.0)
--동해울릉원점(GRS80) EPSG: 5184 (False_Easting: 200000.0 , False_Northing: 500000.0)
--서부원점_2010(GRS80)  EPSG: 5185 (False_Easting: 200000.0 , False_Northing: 600000.0)
--중부원점_2010(GRS80) EPSG:5186 (False_Easting: 200000.0 , False_Northing: 600000.0)
--동부원점_2010(GRS80)-EPSG:5187  (False_Easting: 200000.0 , False_Northing: 600000.0)
--동해(울릉)원점_2010(GRS80)-EPSG:5188  (False_Easting: 200000.0 , False_Northing: 600000.0)

oracle import shp

Oracle Map Builder 프로그램 사용

https://www.oracle.com/technetwork/middleware/mapviewer/downloads/index-100641.html

Using OGR2OGR to re-project a shape file

The syntax for this is :

ogr2ogr -f "ESRI Shapefile" original.shp wgs84.shp -s_srs EPSG:27700 -t_srs EPSG:4326

fwtools-2.4.7    http://fwtools.maptools.org/

C:\geo>gdal_translate -of ECW spcs83ft.tif spcs83ft.ecw
Input file size is 516, 516
0...10...20...30...40...50...60...70...80...90...100 - done.
